什么是http rbac filter

rbac是基于角色的权限控制，http rbac filter是envoy中http类型的权限控制过滤器。我们istio中常用的权限控制资源AuthorizationPolicy，底层就是通过rbac filter实现的。rbac filter 名称为envoy.filters.http.rbac，type固定名称为type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC。rbac filter有两种类型，一种是network过滤器，还有一种是http过滤器，本往篇讲的是http类型的rbac。

配置说明

{ "rules": "{...}", "shadow_rules": "{...}", "shadow_rules_stat_prefix": "..." }

rules: 配置规则

shadow_rules：规则不生效，但会记录日志

shadow_rules_stat_prefix：影子规则的stat前缀

rules:

{ "action": "...", "policies": "{...}" }

action：动作，可以是ALLOW,DENY,LOG

policies:策略配置，包括主体和权限，条件

policies:

{ "permissions": [], "principals": [], "condition": "{...}" }

permissions：权限配置

principals：主体配置

condition：条件配置

permissions:

{ "and_rules": "{...}", "or_rules": "{...}", "any": "...", "header": "{...}", "url_path": "{...}", "destination_ip": "{...}", "destination_port": "...", "destination_port_range": "{...}", "metadata": "{...}", "not_rule": "{...}", "requested_server_name": "{...}" }

and_rules：每个权限都必须满足

or_rules：至少一个权限满足

any：任意权限

header：请求头

url_path：url路径

destination_ip：目标ip

destination_port：目标端口

destination_port_range：目标端口范围

metadata：元数据

not_rule：必须不满足的权限

requested_server_name：请求服务主机名

principals：

{ "and_ids": "{...}", "or_ids": "{...}", "any": "...", "authenticated": "{...}", "source_ip": "{...}", "direct_remote_ip": "{...}", "remote_ip": "{...}", "header": "{...}", "url_path": "{...}", "metadata": "{...}", "not_id": "{...}" }

and_ids：与id，必须都满足主体

or_ids：或id，至少满足一个主体

any：任意主体

authenticated：认证过的主体

source_ip：来源ip

direct_remote_ip：直接远程地址

remote_ip：远程地址

header：请求头

url_path：请求路径

metadata：元数据

not_id：必须不能满足的主体

用rbac filter实现权限控制

allow nothing

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
  name: allow-nothing
spec:
  {}

envoyfilter实现方式

cat << EOF > ef-allow-nothing.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[allow-nothing]-rule[0]:
                  permissions:
                  - notRule:
                      any: true
                  principals:
                  - notId:
                      any: true
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-allow-nothing.yaml -n istio  --context context-cluster1

清理：

kubectl delete -f ef-allow-nothing.yaml -n istio  --context context-cluster1

名称空间拒绝所有

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
  name: deny-all
spec:
  action: DENY
  # This matches everything.
  rules:
  - {}

envoyfilter实现

cat << EOF > ef-deny-all.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              action: DENY
              policies:
                ns[istio]-policy[deny-all]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - any: true
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-deny-all.yaml -n istio  --context context-cluster1

清理：

kubectl delete -f ef-deny-all.yaml -n istio  --context context-cluster1

名称空间允许所有

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: allow-all
spec:
 action: ALLOW
 rules:
 - {}

envoyfilter实现

cat << EOF > ef-allow-all.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[allow-all]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - any: true
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-allow-all.yaml -n istio  --context context-cluster1

from-principals

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - from:
     - source:
         principals: ["cluster.local/ns/istio-system/sa/istio-ingressgateway-service-account"]

envoyfilter实现

cat << EOF > ef-from-principals.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - orIds:
                          ids:
                          - authenticated:
                              principalName:
                                exact: spiffe://cluster.local/ns/istio-system/sa/istio-ingressgateway-service-account
EOF

kubectl apply -f ef-from-principals.yaml -n istio  --context context-cluster1

from-notPrincipals

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - from:
     - source:
         notPrincipals: ["cluster.local/ns/istio-system/sa/test"]

envoyfilter实现

cat << EOF > ef-from-notprincipals.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - notId:
                          orIds:
                            ids:
                            - authenticated:
                                principalName:
                                  exact: spiffe://cluster.local/ns/istio-system/sa/test
EOF

kubectl apply -f ef-from-notprincipals.yaml -n istio  --context context-cluster1

from-requestPrincipals

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
  name: productpage
spec:
  selector:
    matchLabels:
      app: productpage
  action: ALLOW
  rules:
  - to:
    - operation:
        notPaths: ["/healthz"]
    from:
    - source:
        requestPrincipals: ["*"]

envoyfilter实现

cat << EOF > ef-from-requestPrincipals.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - notRule:
                          orRules:
                            rules:
                            - urlPath:
                                path:
                                  exact: /healthz
                  principals:
                  - andIds:
                      ids:
                      - orIds:
                          ids:
                          - metadata:
                              filter: istio_authn
                              path:
                              - key: request.auth.principal
                              value:
                                stringMatch:
                                  safeRegex:
                                    googleRe2: {}
                                    regex: .+
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-from-requestPrincipals.yaml -n istio  --context context-cluster1

from-notRequestPrincipals

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
  name: productpage
spec:
  selector:
    matchLabels:
      app: productpage
  action: ALLOW
  rules:
  - to:
    - operation:
        paths: ["/productpage"]
    from:
    - source:
        notRequestPrincipals:
        - "testing@secure.istio.io/testing@secure.istio.io"

envoyfilter实现

cat << EOF > ef-from-notrequestPrincipals.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - orRules:
                          rules:
                          - urlPath:
                              path:
                                exact: /productpage
                  principals:
                  - andIds:
                      ids:
                      - notId:
                          orIds:
                            ids:
                            - metadata:
                                filter: istio_authn
                                path:
                                - key: request.auth.principal
                                value:
                                  stringMatch:
                                    exact: testing@secure.istio.io/testing@secure.istio.io
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-from-notrequestPrincipals.yaml -n istio  --context context-cluster1

from-namespaces

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - from:
   - source:
       namespaces:
       - "istio-system"

envoyfilter实现

cat << EOF > ef-from-namespaces.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - orIds:
                          ids:
                          - authenticated:
                              principalName:
                                safeRegex:
                                  googleRe2: {}
                                  regex: .*/ns/istio-system/.*
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-from-namespaces.yaml -n istio  --context context-cluster1

from-notNamespaces

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - from:
   - source:
       notNamespaces:
       - "test"

envoyfilter实现

cat << EOF > ef-from-notNamespaces.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - notId:
                          orIds:
                            ids:
                            - authenticated:
                                principalName:
                                  safeRegex:
                                    googleRe2: {}
                                    regex: .*/ns/test/.*
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-from-notNamespaces.yaml -n istio  --context context-cluster1

from-ipBlocks

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: ingressgateway
spec:
 selector:
   matchLabels:
     app: istio-ingressgateway
 action: ALLOW
 rules:
 - from:
   - source:
       ipBlocks:
       - "172.20.0.0/16"

envoyfilter实现

cat << EOF > ef-from-ipBlocks.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: istio-ingressgateway
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: GATEWAY
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio-system]-policy[ingressgateway]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - orIds:
                          ids:
                          - directRemoteIp:
                              addressPrefix: 172.20.0.0
                              prefixLen: 16
EOF

kubectl apply -f ef-from-ipBlocks.yaml -n istio-system  --context context-cluster1

from-notIpBlocks

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: ingressgateway
spec:
 selector:
   matchLabels:
     app: istio-ingressgateway
 action: ALLOW
 rules:
 - from:
   - source:
       notIpBlocks:
       - "172.20.0.0/16"

envoyfilter实现

cat << EOF > ef-from-notIpBlocks.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: istio-ingressgateway
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: GATEWAY
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio-system]-policy[ingressgateway]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - notId:
                          orIds:
                            ids:
                            - directRemoteIp:
                                addressPrefix: 172.20.0.0
                                prefixLen: 16
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-from-notIpBlocks.yaml -n istio-system  --context context-cluster1

from-remoteIpBlocks

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: ingressgateway
spec:
 selector:
   matchLabels:
     app: istio-ingressgateway
 action: DENY
 rules:
 - from:
   - source:
       remoteIpBlocks:
       - 192.168.198.1/32

envoyfilter实现

cat << EOF > ef-from-remoteIpBlocks.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: istio-ingressgateway
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: GATEWAY
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              action: DENY
              policies:
                ns[istio-system]-policy[ingressgateway]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - orIds:
                          ids:
                          - remoteIp:
                              addressPrefix: 192.168.198.1
                              prefixLen: 32
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-from-remoteIpBlocks.yaml -n istio-system  --context context-cluster1

from-notRemoteIpBlocks

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: ingressgateway
spec:
 selector:
   matchLabels:
     app: istio-ingressgateway
 action: ALLOW
 rules:
 - from:
   - source:
       notRemoteIpBlocks:
       - "192.168.198.1/32

envoyfilter实现

cat << EOF > ef-from-notRemoteIpBlocks.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: istio-ingressgateway
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: GATEWAY
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
        - name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio-system]-policy[ingressgateway]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - notId:
                          orIds:
                            ids:
                            - remoteIp:
                                addressPrefix: 192.168.198.1
                                prefixLen: 32
EOF

kubectl apply -f ef-from-notRemoteIpBlocks.yaml -n istio-system  --context context-cluster1

to-hosts

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - to:
   - operation:
       hosts:
       - "bookinfo.demo:30986"
   from:
   - source:
       namespaces:
       - "istio-system"

envoyfilter实现

cat << EOF > ef-to-hosts.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - orRules:
                          rules:
                          - header:
                              name: :authority
                              safeRegexMatch:
                                googleRe2: {}
                                regex: (?i)bookinfo\.demo:30986
                  principals:
                  - andIds:
                      ids:
                      - orIds:
                          ids:
                          - authenticated:
                              principalName:
                                safeRegex:
                                  googleRe2: {}
                                  regex: .*/ns/istio-system/.*
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-to-hosts.yaml -n istio  --context context-cluster1

to-notHosts

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - to:
   - operation:
       notHosts:
       - "test"
   from:
   - source:
       namespaces:
       - "istio-system"

envoyfilter实现

cat << EOF > ef-to-notHosts.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - notRule:
                          orRules:
                            rules:
                            - header:
                                name: :authority
                                safeRegexMatch:
                                  googleRe2: {}
                                  regex: (?i)test
                  principals:
                  - andIds:
                      ids:
                      - orIds:
                          ids:
                          - authenticated:
                              principalName:
                                safeRegex:
                                  googleRe2: {}
                                  regex: .*/ns/istio-system/.*
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-to-notHosts.yaml -n istio  --context context-cluster1

to-ports

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: details
spec:
 selector:
   matchLabels:
     app: details
     version: v1
 action: ALLOW
 rules:
 - to:
   - operation:
       ports:
       - "9080"

envoyfilter实现

cat << EOF > ef-to-ports.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: details
      version: v1
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
        - name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[details]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - orRules:
                          rules:
                          - destinationPort: 9080
                  principals:
                  - andIds:
                      ids:
                      - any: true
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-to-ports.yaml -n istio  --context context-cluster1

to-notPorts

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: details
spec:
 selector:
   matchLabels:
     app: details
     version: v1
 action: ALLOW
 rules:
 - to:
   - operation:
       notPorts:
       - "9080"

envoyfilter实现

cat << EOF > ef-to-notPorts.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: details
      version: v1
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[details]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - notRule:
                          orRules:
                            rules:
                            - destinationPort: 8080
                  principals:
                  - andIds:
                      ids:
                      - any: true
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-to-notPorts.yaml -n istio  --context context-cluster1

to-methods

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: details
spec:
 selector:
   matchLabels:
     app: details
     version: v1
 action: ALLOW
 rules:
 - to:
   - operation:
       methods:
       - "GET"

envoyfilter实现

cat << EOF > ef-to-methods.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: details
      version: v1
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[details]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - orRules:
                          rules:
                          - header:
                              exactMatch: GET
                              name: :method
                  principals:
                  - andIds:
                      ids:
                      - any: true
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-to-methods.yaml -n istio  --context context-cluster1

to-notMethods

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: details
spec:
 selector:
   matchLabels:
     app: details
     version: v1
 action: ALLOW
 rules:
 - to:
   - operation:
       notMethods:
       - "GET"

envoyfilter实现

cat << EOF > ef-to-notMethods.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: details
      version: v1
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[details]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - notRule:
                          orRules:
                            rules:
                            - header:
                                exactMatch: GET
                                name: :method
                  principals:
                  - andIds:
                      ids:
                      - any: true
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-to-notMethods.yaml -n istio  --context context-cluster1

to-paths

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: details
spec:
 selector:
   matchLabels:
     app: details
     version: v1
 action: ALLOW
 rules:
 - to:
   - operation:
       paths:
       - "/details/0"

envoyfilter实现

cat << EOF > ef-to-paths.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: details
      version: v1
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[details]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - orRules:
                          rules:
                          - urlPath:
                              path:
                                exact: /details/0
                  principals:
                  - andIds:
                      ids:
                      - any: true
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-to-paths.yaml -n istio  --context context-cluster1

to-notPaths

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: details
spec:
 selector:
   matchLabels:
     app: details
     version: v1
 action: ALLOW
 rules:
 - to:
   - operation:
       notPaths:
       - "/details/0"

envoyfilter实现

cat << EOF > ef-to-notPaths.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: details
      version: v1
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[details]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - notRule:
                          orRules:
                            rules:
                            - urlPath:
                                path:
                                  exact: /details/0
                  principals:
                  - andIds:
                      ids:
                      - any: true
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-to-notPaths.yaml -n istio  --context context-cluster1

when-request.headers-values

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - when:
   - key: request.headers[test]
     values:
     - "test"

envoyfilter实现

cat << EOF > ef-when-request.headers.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - orIds:
                          ids:
                          - header:
                              exactMatch: test
                              name: test
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-when-request.headers.yaml -n istio  --context context-cluster1

when-request.headers-notvalues

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - when:
   - key: request.headers[test]
     notValues:
     - "test"

envoyfilter实现

cat << EOF > ef-when-request.headers-notvalues.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - notId:
                          orIds:
                            ids:
                            - header:
                                exactMatch: test
                                name: test
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-when-request.headers-notvalues.yaml -n istio  --context context-cluster1

when-source.ip-values

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
 action: ALLOW
 rules:
 - when:
   - key: source.ip
     values:
     - "172.20.0.0/16"

envoyfilter实现

cat << EOF > ef-when-source.ip-values.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - orIds:
                          ids:
                          - directRemoteIp:
                              addressPrefix: 172.20.0.0
                              prefixLen: 16
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-when-source.ip-values.yaml -n istio  --context context-cluster1

when-source.ip-notvalues

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
 action: ALLOW
 rules:
 - when:
   - key: source.ip
     notValues:
     - "172.20.0.0/16"

envoyfilter实现

cat << EOF > ef-when-source.ip-notvalues.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - notId:
                          orIds:
                            ids:
                            - directRemoteIp:
                                addressPrefix: 172.20.0.0
                                prefixLen: 16
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-when-source.ip-notvalues.yaml -n istio  --context context-cluster1

when-remote.ip-values

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
 action: DENY
 rules:
 - when:
   - key: remote.ip
     values:
     - "192.168.198.1/32"

envoyfilter实现

cat << EOF > ef-when-remote.ip-values.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              action: DENY
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - orIds:
                          ids:
                          - remoteIp:
                              addressPrefix: 192.168.198.1
                              prefixLen: 32
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-when-remote.ip-values.yaml -n istio  --context context-cluster1

when-remote.p-notvalues

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
 action: ALLOW
 rules:
 - when:
   - key: remote.ip
     notValues:
     - "192.168.198.1/32"

envoyfilter实现

cat << EOF > ef-when-remote.ip-values.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - notId:
                          orIds:
                            ids:
                            - remoteIp:
                                addressPrefix: 192.168.198.1
                                prefixLen: 32
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-when-remote.ip-values.yaml -n istio  --context context-cluster1

when-source.namespace-values

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
 action: ALLOW
 rules:
 - when:
   - key: source.namespace
     values:
     - "istio-system"

envoyfilter实现

cat << EOF > when-source.namespace-values.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - orIds:
                          ids:
                          - authenticated:
                              principalName:
                                safeRegex:
                                  googleRe2: {}
                                  regex: .*/ns/istio-system/.*
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f when-source.namespace-values.yaml -n istio  --context context-cluster1

when-source.namespace-notvalues

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
 action: ALLOW
 rules:
 - when:
   - key: source.namespace
     notValues:
     - "istio-system"

envoyfilter实现

cat << EOF > ef-when-source.namespace-notvalues.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - notId:
                          orIds:
                            ids:
                            - authenticated:
                                principalName:
                                  safeRegex:
                                    googleRe2: {}
                                    regex: .*/ns/istio-system/.*
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-when-source.namespace-notvalues.yaml -n istio  --context context-cluster1

when-source.principal-values

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - when:
   - key: source.principal
     values:
     - "cluster.local/ns/istio-system/sa/istio-ingressgateway-service-account"

envoyfilter实现

cat << EOF > ef-when-source.principal-values.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - orIds:
                          ids:
                          - authenticated:
                              principalName:
                                exact: spiffe://cluster.local/ns/istio-system/sa/istio-ingressgateway-service-account
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-when-source.principal-values.yaml -n istio  --context context-cluster1

when-source.principal-notvalues

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - when:
   - key: source.principal
     notValues:
     - "cluster.local/ns/istio-system/sa/istio-ingressgateway-service-account"

envoyfilter实现

cat << EOF > ef-when-source.principal-notvalues.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - notId:
                          orIds:
                            ids:
                            - authenticated:
                                principalName:
                                  exact: spiffe://cluster.local/ns/istio-system/sa/istio-ingressgateway-service-account
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-when-source.principal-notvalues.yaml -n istio  --context context-cluster1

when-request.auth.principal-values

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - when:
   - key: request.auth.principal
     values:
     - "testing@secure.istio.io/testing@secure.istio.io"

envoyfilter实现

cat << EOF > ef-when-request.auth.principal-values.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - orIds:
                          ids:
                          - metadata:
                              filter: istio_authn
                              path:
                              - key: request.auth.principal
                              value:
                                stringMatch:
                                  exact: testing@secure.istio.io/testing@secure.istio.io
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-when-request.auth.principal-values.yaml -n istio  --context context-cluster1

when-request.auth.principal-notvalues

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - when:
   - key: request.auth.principal
     notValues:
     - "testing@secure.istio.io/testing@secure.istio.io"

envoyfilter实现

cat << EOF > ef-when-request.auth.principal-notvalues.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
           typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - notId:
                          orIds:
                            ids:
                            - metadata:
                                filter: istio_authn
                                path:
                                - key: request.auth.principal
                                value:
                                  stringMatch:
                                    exact: testing@secure.istio.io/testing@secure.istio.io
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f ef-when-request.auth.principal-notvalues.yaml -n istio  --context context-cluster1

when-request.auth.audiences-values

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - when:
   - key: request.auth.audiences
     values:
     - "app"
     - "web"

envoyfilter实现

cat << EOF > ef-when-request.auth.audiences-values.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - orIds:
                          ids:
                          - metadata:
                              filter: istio_authn
                              path:
                              - key: request.auth.audiences
                              value:
                                stringMatch:
                                  exact: app
                          - metadata:
                              filter: istio_authn
                              path:
                              - key: request.auth.audiences
                              value:
                                stringMatch:
                                  exact: “web”
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f  ef-when-request.auth.audiences-values.yaml -n istio  --context context-cluster1

when-request.auth.audiences-notvalues

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - when:
   - key: request.auth.audiences
     notValues:
     - "app"
     - “web”

envoyfilter实现

cat << EOF > ef-when-request.auth.audiences-notvalues.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - notId:
                          orIds:
                            ids:
                            - metadata:
                                filter: istio_authn
                                path:
                                - key: request.auth.audiences
                                value:
                                  stringMatch:
                                    exact: app
                            - metadata:
                                filter: istio_authn
                                path:
                                - key: request.auth.audiences
                                value:
                                  stringMatch:
                                    exact: “web”
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f  ef-when-request.auth.audiences-notvalues.yaml -n istio  --context context-cluster1

when-request.auth.presenter-values

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - when:
   - key: request.auth.presenter
     values:
     - "app"

envoyfilter实现

cat << EOF > ef-when-request.auth.presenter-values.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - orIds:
                          ids:
                          - metadata:
                              filter: istio_authn
                              path:
                              - key: request.auth.presenter
                              value:
                                stringMatch:
                                  exact: app
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f  ef-when-request.auth.presenter-values.yaml -n istio  --context context-cluster1

when-request.auth.presenter-notvalues

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - when:
   - key: request.auth.presenter
     notValues:
     - "app"

envoyfilter实现

cat << EOF > ef-when-request.auth.presenter-notvalues.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - notId:
                          orIds:
                            ids:
                            - metadata:
                                filter: istio_authn
                                path:
                                - key: request.auth.presenter
                                value:
                                  stringMatch:
                                    exact: app
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f  ef-when-request.auth.presenter-notvalues.yaml -n istio  --context context-cluster1

when-request.auth.claims-values

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - when:
   - key: request.auth.claims[groups]
     values:
     - "group1"

envoyfilter实现

cat << EOF > ef-when-request.auth.claims-values.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - orIds:
                          ids:
                          - metadata:
                              filter: istio_authn
                              path:
                              - key: request.auth.claims
                              - key: groups
                              value:
                                listMatch:
                                  oneOf:
                                    stringMatch:
                                      exact: group1
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f  ef-when-request.auth.claims-values.yaml -n istio  --context context-cluster1

when-request.auth.claims-notvalues

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - when:
   - key: request.auth.claims[groups]
     notValues:
     - "group1"

envoyfilter实现

cat << EOF > ef-when-request.auth.claims-notvalues.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - any: true
                  principals:
                  - andIds:
                      ids:
                      - notId:
                          orIds:
                            ids:
                            - metadata:
                                filter: istio_authn
                                path:
                                - key: request.auth.claims
                                - key: groups
                                value:
                                  listMatch:
                                    oneOf:
                                      stringMatch:
                                        exact: group1
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f  ef-when-request.auth.claims-notvalues.yaml -n istio  --context context-cluster1

when-destination.ip-values

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - when:
   - key: destination.ip
     values:
     - "172.20.0.0/16"

envoyfilter实现

cat << EOF > ef-when-destination.ip-values.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - orRules:
                          rules:
                          - destinationIp:
                              addressPrefix: 172.20.0.0
                              prefixLen: 16
                  principals:
                  - andIds:
                      ids:
                      - any: true
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f  ef-when-destination.ip-values.yaml -n istio  --context context-cluster1

when-destination.ip-notvalues

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - when:
   - key: destination.ip
     notValues:
     - "172.20.0.0/16"

envoyfilter实现

cat << EOF > ef-when-destination.ip-notvalues.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - notRule:
                          orRules:
                            rules:
                            - destinationIp:
                                addressPrefix: 172.20.0.0
                                prefixLen: 16
                  principals:
                  - andIds:
                      ids:
                      - any: true
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f  ef-when-destination.ip-notvalues.yaml -n istio  --context context-cluster1

when-destination.port-values

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - when:
   - key: destination.port
     values:
     - "9080"

envoyfilter实现

cat << EOF > ef-when-destination.port-values.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - orRules:
                          rules:
                          - destinationPort: 9080
                  principals:
                  - andIds:
                      ids:
                      - any: true
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f  ef-when-destination.port-values.yaml -n istio  --context context-cluster1

when-destination.port-notvalues

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - when:
   - key: destination.port
     notValues:
     - "9080"

envoyfilter实现

cat << EOF > ef-when-destination.port-notvalues.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - notRule:
                          orRules:
                            rules:
                            - destinationPort: 9080
                  principals:
                  - andIds:
                      ids:
                      - any: true
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f  ef-when-destination.port-notvalues.yaml -n istio  --context context-cluster1

when-connection.sni-value

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - when:
   - key: connection.sni
     values:
     - "outbound_.9080_._.productpage.istio.svc.cluster.local"

envoyfilter实现

cat << EOF > ef-when-connection.sni-value.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - orRules:
                          rules:
                          - requestedServerName:
                              exact: outbound_.9080_._.productpage.istio.svc.cluster.local
                  principals:
                  - andIds:
                      ids:
                      - any: true
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f  ef-when-connection.sni-value.yaml -n istio  --context context-cluster1

when-connection.sni-notvalue

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
 name: productpage
spec:
 selector:
   matchLabels:
     app: productpage
     version: v1
 action: ALLOW
 rules:
 - when:
   - key: connection.sni
     notValues:
     - "outbound_.9080_._.productpage.istio.svc.cluster.local"

envoyfilter实现

cat << EOF > ef-when-connection.sni-notvalue.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - notRule:
                          orRules:
                            rules:
                            - requestedServerName:
                                exact: outbound_.9080_._.productpage.istio.svc.cluster.local
                  principals:
                  - andIds:
                      ids:
                      - any: true
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f  ef-when-connection.sni-notvalue.yaml -n istio  --context context-cluster1

组合配置

authorizationPolicy实现方式

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
  name: productpage
spec:
  action: ALLOW
  rules:
  - from:
    - source:
        principals:
        - cluster.local/ns/istio-system/sa/istio-ingressgateway-service-account
        namespaces:
        - istio-system
    to:
    - operation:
        methods: ["GET"]
        paths: ["/productpage"]
    - operation:
        methods: ["GET"]
        paths: ["/static/*"]
    - operation:
        methods: ["GET"]
        paths: ["/api/v1/products/*"]
    - operation:
        methods: ["GET"]
        paths: ["/logout"]
    - operation:
        methods: ["POST"]
        paths: ["/login"]
    when:
    - key: source.ip
      values:
      - "172.20.0.0/16"

envoyfilter实现

cat << EOF > ef-combine.yaml
apiVersion: networking.istio.io/v1alpha3
kind: EnvoyFilter
metadata:
  name: match
spec:
  workloadSelector:
    labels:
      app: productpage
  configPatches:
  - applyTo: HTTP_FILTER
    match:
      context: SIDECAR_INBOUND
      listener:
        portNumber: 9080
        filterChain:
          destinationPort: 9080
          filter:
            name: "envoy.filters.network.http_connection_manager"
            subFilter:
              name: "envoy.filters.http.router"
    patch:
      operation: INSERT_BEFORE
      value:
          name: envoy.filters.http.rbac
          typedConfig:
            '@type': type.googleapis.com/envoy.extensions.filters.http.rbac.v3.RBAC
            rules:
              policies:
                ns[istio]-policy[productpage]-rule[0]:
                  permissions:
                  - andRules:
                      rules:
                      - orRules:
                          rules:
                          - header:
                              exactMatch: GET
                              name: :method
                      - orRules:
                          rules:
                          - urlPath:
                              path:
                                exact: /productpage
                  - andRules:
                      rules:
                      - orRules:
                          rules:
                          - header:
                              exactMatch: GET
                              name: :method
                      - orRules:
                          rules:
                          - urlPath:
                              path:
                                prefix: /static/
                  - andRules:
                      rules:
                      - orRules:
                          rules:
                          - header:
                              exactMatch: GET
                              name: :method
                      - orRules:
                          rules:
                          - urlPath:
                              path:
                                prefix: /api/v1/products/
                  - andRules:
                      rules:
                      - orRules:
                          rules:
                          - header:
                              exactMatch: GET
                              name: :method
                      - orRules:
                          rules:
                          - urlPath:
                              path:
                                exact: /logout
                  - andRules:
                      rules:
                      - orRules:
                          rules:
                          - header:
                              exactMatch: POST
                              name: :method
                      - orRules:
                          rules:
                          - urlPath:
                              path:
                                exact: /login
                  principals:
                  - andIds:
                      ids:
                      - orIds:
                          ids:
                          - authenticated:
                              principalName:
                                exact: spiffe://cluster.local/ns/istio-system/sa/istio-ingressgateway-service-account
                      - orIds:
                          ids:
                          - authenticated:
                              principalName:
                                safeRegex:
                                  googleRe2: {}
                                  regex: .*/ns/istio-system/.*
                      - orIds:
                          ids:
                          - directRemoteIp:
                              addressPrefix: 172.20.0.0
                              prefixLen: 16
            shadowRulesStatPrefix: istio_dry_run_allow_
EOF

kubectl apply -f  ef-combine.yaml -n istio  --context context-cluster1
